Frame
Size: XXS , XS
Alpha Silver Aluminium, curved top tube, internal derailleur and dropper post routing, rack and kickstand mount, 135x5 mm ThruSkew
Size: S , M , ML , L , XL , XXL
Alpha Silver Aluminium, internal derailleur and dropper post routing, rack and kickstand mount, 135x5 mm ThruSkew
Fork
Size: XXS
RockShox Judy, coil spring, preload, TurnKey lockout, 42 mm offset for 27.5" wheel, 100 mm QR, 80 mm travel
Size: XS , S
RockShox Judy, coil spring, preload, TurnKey lockout, 42 mm offset for 27.5" wheel, 100 mm QR, 100 mm travel
Size: M , ML , L , XL , XXL
RockShox Judy, coil spring, preload, TurnKey lockout, 46 mm offset for 29" wheel, 100 mm QR, 100 mm travel
Max compatible fork travel
120mm, XXS: 80mm
Hub front
Formula DC-20, alloy, 6-bolt, 100 mm ThruSkew
Hub rear
Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR
Rim
Bontrager Kovee, double-wall, Tubeless-Ready, 28-hole, 23 mm width, Presta valve
Tyre
Size: XXS
Bontrager XT3 Elite, Tubeless Ready, Inner Strength casing, wire bead, 60 tpi, 26x2.35"
Size: XS , S
Maxxis Ardent Race, tubeless, EXO casing, folding bead, 60 tpi, 27.5x2.35"
Size: M , ML , L , XL , XXL
Maxxis Ardent Race, tubeless, EXO casing, folding bead, 60 tpi, 29x2.35"
Max tyre size
Frame: 29x2.40" (XXS: 26x2.40", XS & S: 27.5x2.40"), Fork: See manufacturer
Shifter
Shimano U6000, 10-speed
Rear derailleur
Shimano CUES U6000 GS
Crank
Size: XXS , XS
FSA Alpha Drive, 30T, 160 mm length
Size: S , M , ML
FSA Alpha Drive, 30T, 170 mm length
Size: L , XL , XXL
FSA Alpha Drive, 30T, 175 mm length
Bottom bracket
FSA, 73 mm, threaded cartridge, 122.5 mm spindle
Cassette
Shimano CUES LG300, LINKGLIDE, 11-48, 10-speed
Chain
Shimano LG500
Pedal
VP-536 nylon platform
Max. chainring size
1x: 34T, 2x: 36/22
Saddle
Bontrager Verse Short, stainless steel rails
Seatpost
Size: XXS
Bontrager alloy, 31.6 mm, 12 mm offset, 300 mm length
Size: XS , S , M
Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length
Size: ML , L , XL , XXL
Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length
Handlebar
Size: XXS , XS
Bontrager alloy, 31.8 mm, 5 mm rise, 690 mm width
Size: S
Bontrager alloy, 31.8 mm, 15 mm rise, 720 mm width
Size: M , ML , L , XL , XXL
Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width
Grips
Bontrager XR Trail Comp, nylon lock-on
Stem
Size: XXS , XS , S
Bontrager alloy, 31.8 mm, Blendr-compatible, 7-degree, 35 mm length
Size: M , ML , L
Bontrager alloy, 31.8 mm, Blendr-compatible, 7-degree, 50 mm length
Size: XL
Bontrager alloy, 31.8 mm, Blendr-compatible, 7-degree, 60 mm length
Size: XXL
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 70 mm length
Head set
Semi-integrated, 1-1/8"
Brake rotor
Tektro, 6-bolt, 160mm
Brake Set
Size: XXS , XS , S
Tektro HD-M276 hydraulic disc, short reach
Size: M , ML , L , XL , XXL
Tektro HD-M275 hydraulic disc
Rotor size
Max brake rotor sizes - Frame: 180mm (XXS: 160mm), Fork: see fork manufacturer
Weight
M - 14.50 kg / 31.97 lbs (with tubes)
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
