Frame
Alpha Platinum Aluminium, internal storage, angle-adjust headset, Mino Link adjustable geometry, adjustable leverage rate, guided internal routing, magnesium rocker link, 34.9 mm seat tube, ISCG 05, 55 mm chain line, BSA 73, downtube guard, shuttle guard, ABP, UDH, Boost148, 140 mm travel
Fork
Size: XS, S RockShox Recon Silver, Solo Air spring, Motion Control damper, lockout, tapered steerer, 46 mm offset, Boost110, Maxle Stealth, 140 mm travel Size: S, M, ML, L, XL, XXL RockShox Recon Silver, Solo Air spring, Motion Control damper, lockout, tapered steerer, 42 mm offset, Boost110, Maxle Stealth, 150 mm travel
Shock
X-Fusion Pro 2, 2-position damper, 185 mm x 55 mm
Max Compatible Fork Travel
160 mm
Hub Front
Bontrager alloy, 6-bolt, Boost110, 15 mm thru-axle
Hub Rear
Bontrager alloy, sealed bearing, 6-bolt, Shimano MicroSpline freehub, Boost148, 12 mm thru axle
Skewer Rear
Bontrager Switch thru-axle, removable lever
Rim
Bontrager Line TLR 30, Tubeless-Ready, 32-hole, Presta valve
Tyre
Size: XS, S Bontrager Gunnison Elite XR, Tubeless Ready, wire bead, 60 tpi, 27.5x2.40" Size: S, M, ML, L, XL, XXL Bontrager Gunnison Elite XR, Tubeless Ready, wire bead, 60 tpi, 29x2.40"
Tyre Part
Bontrager TLR sealant, 180 ml/6 oz
Rim Strip
Bontrager TLR
Max Tyre Size
Frame: 29x2.50" (XS & S: 27.5x2.50"), Fork: See manufacturer
Shifter
Shimano Deore M6100, 12-speed
Rear Derailleur
Shimano Deore M6100, long cage
Crank
Shimano MT512, 30T ring, 55 mm chain line, 170 mm length
Bottom Bracket
Shimano BB-MT501 BSA
Cassette
Shimano Deore M6100, 10-51, 12-speed
Chain
Shimano Deore M6100, 12-speed
Max. Chainring Size
1x: 34T round, 32T oval, min 28T
Saddle
Size: XS, S, M, ML, L, XL, XXL Bontrager Arvada, steel rails, 138 mm width Size: XS, S, M, ML, L, XL, XXL Bontrager Verse Short, stainless steel rails
Seatpost
Size: XS, S TranzX JD-YSI-22PLQ, 100 mm travel, internal routing, 34.9 mm, 346 mm length Size: M, ML TranzX JD-YSI-22PLQ, 150 mm travel, internal routing, 34.9 mm, 454 mm length Size: L, XL, XXL TranzX JD-YSI-22PLQ, 170 mm travel, internal routing, 34.9 mm, 497 mm length
Handlebar
Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width
Grips
Bontrager XR Trail Comp, nylon lock-on
Stem
Size: XS, S Bontrager Comp, 31.8 mm, 7-degree, 35 mm length Size: M, ML, L, XL, XXL Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length
Head Set
Integrated cartridge bearing, 1-1/8" top, 1.5" bottom, angle adjust cup compatible
Brake
Shimano hydraulic disc, MT201 lever, MT200 calliper
Brake Rotor
Shimano RT56, 6-bolt, 180 mm
Rotor Size
Max brake rotor sizes – Frame: 203 mm, Fork: see fork manufacturer
Bag
Bontrager BITS Internal Frame Storage Bag
Weight
M - 15.80 kg/34.84 lb
Weight Limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
