Frame
Ransom Carbon HMXIntegrated Suspension Technology6 Link kinematic / Adjustable head angleSyncros Cable Integration SystemBB92 / UDH Interface / 12x148mm with 55mm Chainline / MX Ready
Fork
FOX 38 Float Factory Grip 2 Air / KashimaHSC - LSC - HSR- LSR adjustable / Kabolt 15x110mm axle44mm offset / tapered steerer170mm travel
Rear Shock
FOX FLOAT X NUDE Factory EVOL Piggy Back TrunnionKashima / SCOTT custom w. travel / geo adj.3 modes: Climb-Ramp Control-DescendCustom large Air volume / Comp & Reb. Adj.Travel 170-130-Climb / T205X65mm / Bearing Hardware
Remote System
TracLoc TechnologyRear Suspension & Dropper Remote3 Rear Suspension modes
Rear Derailleur
SRAM X0 Eagle AXS Transmission 12 SpeedWireless Electronic Shift System
Shifters
SRAM AXS Rocker Controller
Crankset
SRAM X0 Eagle TransmissionBash guard / DUB / 55mm CL / 32T
Chainguide
SCOTT custom
BB-Set
SRAM DUB PF 92 MTB Wide / shell 41x92mm
Chain
SRAM CN X0 Eagle Transmission
Cassette
SRAM X0 Eagle XS 1295 Transmission 10-52
Brakes
SRAM Code Ultimate Stealth 4 Piston Disc
Rotor
SRAM HS2 Rotors F&R 200mm
Handlebar
Syncros Hixon iC CarbonSize S & M 15mm rise / Size L & XL 25mm riseback sweep 8° / 780mm / 40mmSyncros Endurance lock-on grips
Seatpost
Syncros Duncan Dropper Post 1.5S / Travel Adjust / 31.6mmS size 140mm / M size 180mm / L & XL size 210mm
Seat
Syncros Tofino 1.5Titanium Rails
Headset
Syncros - Acros Angle adjust & Cable Routing HS System+-0.6° head angle adjustmentZS56/28.6 – ZS56/40 MTB
Wheelset
Race Face Turbine R 30 / 110x15 / 148x12 rear / 29" / 28H / Tubeless Ready Rims / XD driverSyncros Axle w/Removable Lever with Tool
Front Tire
Maxxis Assegai / 2.5" / 60TPI Foldable / EXO+ / TR / 3C Maxx Gripp
Rear Tire
Maxxis Dissector / 2.4" / 120TPI Foldable / DD/ TR / 3C Maxx Terra
Extras
SRAM AXS PowerpackSyncros Trail Fender 2 36/38Syncros Eco Sealant
Accessories
Syncros IS Matchbox kitSyncros IS tubeless Handlebar tool / Syncros Multi-tool Matchbox 8
Approx weight in KG
15.2 (Tubeless setup without Matchbox IS)
Approx weight in LBS
33.51 (Tubeless setup without Matchbox IS)
Max. System Weight
128 kgThe overall weight includes the bike, the rider, the equipment, and possible additional luggage.
